Ford 6.7 power stroke oil starvation issues revealed

Bad engineering, bad engineering – this is nuts here’s what air does to it. Somebody’S got a problem here I got to fix hey good morning, everybody before I show you the video I’m about to show you. I wanted to talk to you about something. I’M an engine builder and uh. What that means to me is Building engines, obviously, but it means building them better than they were already built or I’m not an engine builder, I’m just a parts hanger, I’m just a guy that you know takes stuff apart and puts it back together and that’s a Good start, I mean you know, that’s we all start there, but after 34 years in my own shop, almost 50 years of doing this, I uh I I want to make a better product, and so a lot of you out there are are saying my goodness

Uh he’s try, you know he there’s problems here, there’s problems there, there’s problems everywhere and uh. A guy I follow Steve Morris is an engine builder and he blow he. He builds uh blown Motors that that blow your mind and uh. He doesn’t build everything that I build, he’s very specific and he’s he’s a lot smarter than I am but uh. I follow him because what I like about him is he he just wants to find better and better and better that’s the best way.

 I can explain it and that’s what I do as an engine builder, so the video I’m about to show you is going to talk about a 67 power stroke and some of the issues that we’re having spun main bearing SP. You know lost oil pressure in the in the oil in the cam shaft and some of my reasoning for that and some of the fixes that I think should happen every engine I built every engine I built, I’m I’m built this way. I want to find a better way to do it, so I’m looking for the failure points in them and every engine 4D GM Toyota every engine has failure, points we’re good engine builders. We want to fix those I’m going to find some things out here and it’s not pretty it it’s kind of like you just want to slap some people and go what were you thinking? So let me talk about this.

This is the oil pan off of a 67, it’s obviously cleaned and a lot better. Here’S a block – and I’m going to I’m going to walk you through here some of my concerns and we’re going to we’re going to figure out the truth about this. This pickup tube, I’m just curious. Oh my goodness, this thing is a fullon inch and a qu B pipe. So first thing I want to find out is how much oil does that thing hold, because here’s here’s the first thing that I got issues with.

So this is down this. This pickup tube is down in the pan and, of course, this is where our sump sits, and this is where all the oil uh, I think these things take 12 quarts of oil, or something like that. This is basically where all the oil sits that oil does not come up higher than this in the pan. It it doesn’t so now we’ve got to fill all this up. Then it comes to here, which is the inlet side of the oil pump, and then the oil pump pumps it up.

That’S the front of the engine, the crank shaft, the oil pump pumps it up. Then it pressurizes it now, it’s pressurized and it pushes it down through here – runs through this tube all the way down through here and comes out right here into the I’ve taped this up, because the guy uh this customer wants a purple oil pan um. It comes out feeds through the oil cooler here and then goes back into. The pan here crosses the pan inside this tube here to the other side, this is where the oil filter housing bolts to PR feeds. The oil filter goes through the oil filter back into the engine and comes up this tube here and then it and that hole there is right.

Uh. Let me show you where it’s at here that hole. There is right here so that hole in the pan here sits right there, okay, so now we’re going to take we’re going to take some measurements here, we’re going to figure some stuff out, get this right there. It is right there like that, okay, so this engine’s upside down, here’s my question: how much freaking oil is in all these holes in these tubes that drains out of the motor before it gets into the motor to the bearings I’m going to take this gallon water Jug and I’m going to start filling this stuff up, I’m going to do a little experiment. Cuz, it’s a concern to me.

I you know my guess is: there’s two quarts of oil in here. So we’re going to fill this stuff up with just some water and take a measurement and find out how much oil are we draining out of this thing before this engine charges up: okay, here’s an old barar brush that we use to clean out these boes and Stuff, so we’re going to just kind of like look here so now, so the oil gets pressurized down through this hole. And if you look here, this is galley. Now we’ve pulled these plugs out of here, cuz we brush motors, you know we we clean all this out, but then the oil come comes through here goes up through here. This is the cam.

Now I want to show you something about the cam shaft on this motor. Now this cam shaft is wiped out a lobe on here, but so this is junk, but this is the cam shaft out of a 67. So now the oil comes, the oil comes pushes gets pushed here through this oil Port goes through the engine. Now it comes, it come it’s charged. It charges this m up and this rear.



The oil here goes to this. This is the cam bearing the rear Cam. Bearing that rear Cam, Bearing goes right here in this journal, now look at the little hole. Here’S a hole, there’s one right, there look there’s another hole, another hole. These are bearing journals on this cam.

This is what’s like. I don’t get it. You look in this block now everybody that builds Motors you’re going to know normally the mains would oil the cam board you just they would have gun drilled this. This uh Journal right here to where the cam, bearing goes I’ve, got the bearings out of it, but this is the that that’s the housing that would house the bearing Journal all of them in here, not this motor. I guess they thought it was smart enough that we’re going to we’re going to L every cam journal on that motor through this port by having that that the cam shaft is hollow.



So now I got to fill up this hollow cam shaft. I can pull this. I’M going to pull that I’m going to pull that plug out of there and we’re going to we’re going to fill this cam shaft up we’re going to find out how much oil that holds before this engine sees lubrication on the bearing journals. That’S what I’m after here, I want to know how oil starve this engine really is on a cold startup, and that’s what we’re going to do. Okay, so here’s a brand new cam uh that we’re that we’re going to put in a a 67.

It’S a performance! Cam an upgrade stage one. They don’t come with oil uh plugs, but you can see how big the hole is in there. So I’m going to tape up all these holes here, just some tape, I’m going to wrap them up and we’re going to pour water in here we’re going to find out what our volume is in this cam. What our volume is of oil uh in the pan, and everything like that – I just need to cover the holes – is all I don’t need we’ll start filling this and we’ll keep track of how much we got that’s how much the cam shaft takes.



Okay, now we’re going to fill up the oil cooler now this is the oil part of the oil cooler this. This is where the coolant goes so we’re going to set this here, and this will take a little longer to fill, because it’ll want to oop whoop whoop trying to be accurate here about topping that off. So that’s the oil cooler now this is your oil filter. Now this isn’t going to fill up the way I’d like it to, but we’re going to just tell you. I mean this is an old oil filter, but that’s at least a quart.

I mean and and and guys this is important. Most people aren’t out there changing the role they’re going to Jiffy Lube or you know their tire store or whoever and man. You better hope, the guy. That’S changing. Your oil takes a time to let this oil filter fill up with oil and doesn’t just screw on one without oil.



In it everybody knows you should fill up your oil filter, your new one when you change it with oil, so that you’re not pumping air through this thing, but let’s just kind of see how much we can get in there. Okay, so we’re done there. Okay! Now, I’m really not going to worry too much about filling up these these galys in the block you know we can. We can make some assumptions that maybe there’s a quarter of a quart in there, but let’s, let’s do this.

One now Joy hold this for me. Okay, so so now dump it out. Oh [, __ ], that’s a lot of okay. I think we got it. Okay, all right and what we haven’t got here.



Yet is the oil pump housing that would sit here? The oil pump is going to drain, but we’ve definitely got a half a gallon two quarts. I was kind of thinking two two and a half quarts, so I was pretty close. Everybody bad engineering, bad engineering. This is nuts.

You expect this motor to survive after an oil change when you drain all that out of there and also when it sits for a while, I don’t know, but we’re going to to find out how long it takes to get oil pressure up to our bearings. Let me show you what air does up against oil oil. You want that on the bearing surface, here’s what air does to it, pushes it right out of the way you don’t have any oil up against your bearing it’s. It’S Insanity somebody’s got a problem here, so this the power stroke. This is how they, so they they’ve got these oil tubes sitting over the Rockers.



Now a lot of people don’t know on this engine. They have got um push rods for every valve. That’S why there’s just a ton of push rods in here and those push rods, go down to a lifter that looks like this and in that lifter there’s two. This is the roller, the housing for it, and it’s got two of these little lash adjusters and those lash adjusters sit at the bottom of these push rods. Now everybody knows this motor is famous there.

So you read on the internet, there’s so many people complaining, hey man. I changed my oil and the thing just clatters forever um after I, after I have my oil, changed it clatters on Startup and it doesn’t go away. It takes a while. This is why it doesn’t go away. Remember the air and the oil whenever you introduce air into a hydraulic system, which is what oil pressure is a hydraulic system.



You’Re um basically collapsing all these lifters and that’s what the clatter is. This is, and – and Ford has has got a problem with this and the other problem that I see in in their lifters are, and I I never like these kind of lifters you can see there’s little needle bearings in there see those little needle bearings. Now you go to a racing lifter a roller racing lifter. They they ain’t, got no needle bearings in that thing, because I’m going to show you here on a piece of paper, why here’s a here’s, a lifter – that’s that’s! That’S failing!

The pin is actually coming out of the lifter and it’s starting to fail when that fails. You you’re going to grenade your motor, but let me let me show you why needle bearings are not the way to go on heavy spring pressure uh. So if ever you do any performance work, you want to get away from this heavy spring pressure. You want to get away from this, and let me show you I want to talk about the problem I have with needle bearings uh in a lifter and the best way I could do that. I think, is to show you something.



Let me draw this out. Just use this, I’m not a good drawer, so I’m going to draw a half circle on [ Music ] that and then I’m going to draw an outer ring like this. Okay, our needle bearings, are inside that lifter like this and they’re all the way around there. Now my point is, and a motion is different: I’ll show you how that works. My point is is how much load is distributed on those little points so where the needle bearings touch the inner shaft and the outer shaft of that roller lifter, and that that roller is turning on this?

It’S better. It’S proven better! That’S why Racers do it. We put a bushing in here and it’s solid and it’s a bushing is solid, and so we have an oil film running here and an oil film running here and we distribute the load much better. That way, so a bushing all the way around in here – and this is solid, like a bronze bushing.



This is solid. You just get a little oil film in there thousand of an inch and uh. It last takes a load better and it lasts a lot longer. So that’s one of the things we want to look at for this foil uh. You know the the lack of lubrication.

We want to try to figure out how we can best not have an issue with that. I’Ve got a 67 built ready to go in a uh, a truck, and I I want to show you a few things somebody had said to me: what’s all the blue tape, for we do that for safety and look here any ho any opening see we put An exhaust manifold on this side, we haven’t done it on this side. We do that because, yes, it’s true, I we have put Motors in vehicles before where we’ve dropped a little nut or something inside one of these intakes or exhaust port, and it’s gone through the motor. We you know, we have done that, and a simple thing like tape on there will will keep that anything from falling in there till you’re ready to put the component on there just a little tip but come over here. I want to show you something and we’re going to do this test to prove my point about how much oil this is where the turbo sits on this pedestal and I believe one of these holes is coolant and the other’s oil.



I think this is the oil one here, but we’re going to we’re going to find out which one and we’re going to uh. What – and this is my this is my contention. I’M going to start the motor up in my sim test machine and that’ll be a another video that I’m going to show you it’ll take me about a week, but I’m going to put this engine on my SIM test machine without the fix in it. Without the fix – and I want to see how long it takes before I charge this engine up like we’ve – talked about it’s 2 quart low when it drains out. How long does it take before?

I see oil up here and this oil hole right here? Gets its oil pressure from the lifter Galley? The lifters are right here, so I’ve got to I’ve got to charge my main bearings. I’Ve got to charge my uh Hollow cam shaft, I charge my lifters and then the turbo gets oil pressure here and we want a time. How long does that take?



I don’t know, but we’re going to find out what I’m going to do. Is I’m going to take that 67 back there, I’m going to put it in my sim test machine, I’m going to run this thing up to 500 RPM! That’S about cranking, uh speed! When the when the engine starting and I’m going to see how fast I get oil pressure in there, that video me testing it without my fix and with my fix will be in about a week um and follow me and we’ll uh we’ll have that ready. For you, thanks
